Unlock the full potential of your Nissan RB26DETT engine with the HKS Step Pro V-CAM Camshaft System. Engineered for serious performance enthusiasts, this advanced system delivers exceptional power gains and improved responsiveness across the entire rev range.

Key Features

• Variable Valve Timing: Optimises intake cam timing for superior torque and horsepower.
• High-Performance Camshaft: Designed for aggressive tuning while maintaining drivability.
• Precision Engineering: Developed by HKS for maximum reliability under extreme conditions.

Specifications

• Duration: 264°
• Valve Lift: 10.0 mm
• Valve Timing: 80°–130°

Benefits of V-CAM Technology

The Step Pro V-CAM system is the ultimate upgrade for RB26 enthusiasts seeking cutting-edge technology and proven performance. Whether you’re building a street monster or a track-dominating machine, this system ensures optimal valve timing for unmatched acceleration and top-end power.

• Enhanced Mid-Range Torque: V-CAM adjusts intake timing dynamically, delivering strong torque where RB26 engines typically lag.
• Improved Throttle Response: Faster cam timing adjustments mean instant power delivery for spirited driving.
• Broader Power Band: Enjoy smooth acceleration from low RPMs to high revs without sacrificing top-end performance.
• Better Fuel Efficiency: Optimised valve timing reduces pumping losses, improving efficiency during cruising.
• Track-Proven Reliability: Designed for high-stress environments, ensuring consistent performance under extreme loads.
• Customisable Tuning: Works seamlessly with aftermarket ECU setups for fine-tuned performance goals.

Notes

• Compatible with exhaust camshafts with 272° or above duration
• Heavy duty valve springs required
• 8,800 rpm rated engine limit
• Camshaft has reduced base circle ⌀ 31.0 mm (stock ⌀ 32.0mm)
• Requires cylinder head modification
• Requires piston with sufficient valve reliefs
• Recommend engine oil weight of 10W-50 or 15W-50

Package Contents:

• 1 × Cylinder Head Cover, Intake side
• 1 × Oil Control Valve (OCV)
• 1 × Camshaft Angle Sensor
• 2 × Flange Bolt (M6×14)
• 1 × Adaptor Connector (M16–1/8" NPT)
• 1 × Oil Filter
• 1 × Cylinder Head Cover Gasket, Intake side
• 1 × Oil Filler Cap
• 1 × Name Plate
• 1 × Camshaft Step Pro (264°-10.0 mm)
• 1 × Socket Head Flange Bolt (M12×35)
• 1 × Variable Valve Timing Unit Step Pro
• 1 × Cover Plate
• 3 × Extra Low Head Bolt (M5×10)
• 1 × Oil Line Adaptor
• 2 × Joint Pipe
• 4 × O-Ring (ID 5.5 mm)
• 1 × Adaptor Plate
• 4 × Camshaft Cap Bolt
• 4 × Self Lock Nut (M6)
• 4 × Flat Washer (M6)
• 1 × Spacer
• 1 × Flat Head Bolt (M8×15)
• 1 × Rubber Washer (20×12×3 mm)
• 1 × Flexible Hose (600 mm w/2 Nipples)
• 1 × Hexagon Fitting
• 1 × T-Fitting (1/8" NPT)
• 1 × Harness (Includes a wiring diagram)
• 1 × Instruction Manual
