Push your Toyota 2JZ-GTE engine build to the next level with the Artec Performance T4 Twin Scroll Exhaust V-Band Exhaust Manifold. Engineered for high-horsepower applications, this manifold combines advanced design with investment casting technology to deliver superior strength, flow, and reliability compared to traditional fabricated manifolds.

Key Features:

Designed for T4 Twin scroll turbochargers.
Designed for high-performance 2JZ-GTE engines.
36mm ID Runners.
Built to handle extreme boost and track conditions.
Industry leading SUS347 stainless steel investment cast exhaust manifold with allows ARTEC manifolds to deliver superior flow and efficiency. Smoother merging angles can be achieved versus traditional manifolds, and tight radius bends and runners can also be eliminated which can cause restriction.
Rated for 1200+ wheel horsepower
RHD and LHD Compatible
Can also be fitted using the OEM Toyota studs, no need to cut or replace

Compatibility:

Engine:
- Toyota 2JZ-GTE
- Toyota 2JZ-GTE VVT-i
Chassis:
- Toyota Supra JZA80
- Toyota Aristo JZS147
- Toyota Aristo JZS161
Wastegate: Dual external wastegates for superior, highly precise boost control
- Designed for dual Turbosmart, Precision and GFB wastegates 44–46mm wastegates
Turbocharger: 70mm STANDARD ROTATION turbocharger with v-band flange
- Garrett with T4 Twin Scroll Inlet
  - Garrett G-Series/G-Series Ⅱ G30
  - Garrett G-Series/G-Series Ⅱ G35
  - Garrett G-Series/G-Series Ⅱ G40
  - Garrett G-Series/G-Series Ⅱ G42
  - Garrett G-Series/G-Series Ⅱ G45
  - Garrett GTX35/GTX35 Gen Ⅱ R/R
  - Garrett GT35
- Precision with T4 Twin Scroll Inlet
  - Next Gen 5662
  - Next Gen 6062
  - Next Gen 6670
  - Next Gen 6870
  - Next Gen 6875
  - Next Gen 7275
  - Gen 2 PT5862
  - Gen 2 PT6062
  - Gen 2 PT6066
  - Gen 2 PT6266
  - Gen 2 PT6466
  - Gen 2 PT6870
  - Gen 2 PT6875
  - Gen 1 PT5562
  - Gen 1 PT5862
  - Gen 1 PT5866
  - Gen 1 PT6262
  - Gen 1 PT6266
  - Gen 1 PT6766
  - Gen 1 PT8285 H-Cover
- Turbosmart with T4 Twin Scroll Inlet
  - TS-1-6466B
  - TS-2-6466B
  - TS-2-6870B
- BorgWarner with T4 Twin Scroll Inlet
  - EFR 7064-D
  - EFR 7670-D
  - EFR 8370-D
  - EFR 8374-D/H
  - EFR 8474-D/H
  - EFR 9174-D/H
  - EFR 9274-D/H
  - EFR 9180-D/H
  - EFR 9280-D/H
  - AirWerks S300SX3
  - AirWerks S300SX-E
  - AirWerks S300SX-R
  - AirWerks S400SX
- Turbochargers from other manufacturers may fit provided they use the same flange diameters, profiles and are reverse rotation

Why Investment Casting?

Unmatched Strength & Durability: One-piece cast construction eliminates welds, removing common failure points under extreme heat and boost.
Optimised Flow: Smooth internal surfaces reduce turbulence, improving exhaust gas velocity for faster spool and maximum efficiency.
Consistent Quality: Precision moulding ensures uniform wall thickness and perfect fitment every time.
Compact Design: Casting allows for complex shapes that maximise clearance and simplify installation in tight spaces.

Why Choose Artec Performance?

Artec Performance sets the benchmark for exhaust manifold technology. By leveraging investment casting, they deliver a product that outperforms fabricated designs in strength, reliability, and flow efficiency—perfect for high-power 2JZ builds and competitive motorsport applications.
