When fuel starvation isn’t an option, the FPG In-Tank Surge Tank Kit delivers the reliability and performance serious builds demand. Developed to meet the increasing fuel requirements of modern high-horsepower street, circuit and drift cars, this complete in-tank surge solution has been extensively track tested across a range of applications with outstanding results.

Featuring an anodised surge tank and CNC-machined billet components, the system allows the installation of one or two primary fuel pumps plus a dedicated lift pump, ensuring the surge tank remains full even during low fuel conditions and high-G cornering. The result is race-proven fuel delivery while retaining an OEM-style footprint and requiring no modifications to the factory fuel tank.

Capable of supporting over 1000 WHP on E85, this is the ultimate fuel system upgrade for serious performance enthusiasts looking for maximum reliability and performance.

Key Features

• Complete in-tank surge tank system with OEM-style fitment
• Supports single or twin main fuel pumps plus a dedicated lift pump
• Anodised surge tank with CNC-machined billet hat and components
• Track tested in drifting, circuit racing and high-performance street applications
• Supports over 1000 WHP on E85
• No modifications required to the factory fuel tank
• Compatible with all fuel types
• Factory-calibrated fuel level sender operation
• Suitable for OEM instrument clusters and aftermarket digital dashes
• Individual pump power supply through integrated 4-pin hat connector
• Built-in grounding bosses on the top and underside of the billet hat
• Interchangeable fittings using M18x1.5 threaded ports

Fuel Pump Compatibility

The revised mounting design allows compatibility with a wide range of popular performance fuel pumps, including:

• BKS1000 Brushless Fuel Pump
• BKS1001 Brushless Fuel Pump
• Walbro / Ti Automotive 450, 460, 525 and 535 E85 Fuel Pumps
• AEM 340LPH Fuel Pumps
• Raceworks 340LPH Fuel Pumps
• DeatschWerks 340LPH Fuel Pumps
• Other fuel pumps featuring 3/8" (10mm) outlet barbs

Note: Fuel pumps with 5/16" (8mm) outlet barbs, including Walbro 255 and various Sard fuel pumps, are not compatible with this kit.

Flexible Fitting Options

The billet hat is available with multiple fitting configurations to suit your fuel system requirements:

• 5/16" Barb
• 5/16" GM Quick Connect
• -6AN
• -8AN
• -10AN

All ports use M18x1.5 female threads, allowing fittings to be changed or upgraded at any time.

Lift Pump Recommendations

The lift pump can be any fuel pump with a 38-39mm body diameter.

Recommended Lift Pump: Pierburg 7.21088.62.0

Fuel Level and Wiring

The supplied fuel level sender is calibrated with the same resistance values as the factory sender, ensuring seamless compatibility with:

• Factory instrument clusters
• Aftermarket digital dash systems when configured correctly

Connectors for the billet hat are included and supplied with both barrel-crimp and F-crimp terminals. Matching Nissan-style connectors are also available separately, allowing installation without cutting into the factory wiring loom.

Important Notes

• Fuel pumps are not included and must be purchased separately.
• The kit uses 10mm flexible fuel tubing throughout.
• Walbro 535 (F90000295) pumps do not feature internal check valves and require additional check valves when used in staged multi-pump configurations.
• Always consult your tuner when designing a fuel system to ensure it is suitable for your intended power level and application.
• FPG Tank Access Covers are recommended for improved clearance and easier wiring installation.

What’s Included

• CNC-machined billet surge tank assembly
• Billet fuel pump hat
• Fuel level sender assembly
• Fuel pump strainers
• Internal fuel hoses
• Hose clamps
• Deutsch wiring connectors
• Hat connectors and terminals
• New fuel tank seal

Simply add your preferred fuel pumps and complete the wiring for a race-proven in-tank fuel system capable of supporting serious horsepower while maintaining factory-style fitment and reliability.
