Designed and manufactured by Frenchy’s Performance Garage, this twin pump in‑tank fuel system hanger kit is a high‑quality solution for high‑power Nissan Skyline R32 & 180SX/Silvia S13 applications with a factory steel fuel tank. Featuring a fresh V3 billet hat design, this system is engineered for reliability, modern wiring standards, and long‑term performance across all fuel types.

The kit is designed to support high‑horsepower builds exceeding 1000hp on E85 when paired with suitable fuel pumps, making it ideal for serious street and motorsport applications. (Fuel pumps not included.)

Vehicle Fitment

• Nissan Silvia (P)S13
• Nissan 180SX R(P)S13
• Nissan Skyline R32 GTS-t/GTS-4

Key Features

• Single or Twin in‑tank fuel pump configurable for high fuel flow capability
• Designed for steel fuel tank vehicles
• High‑current 6‑pin electrical bulkhead with enough pins to power two pumps and the fuel level sender
• E85 compatible components and tubing
• Convoluted fuel tubing for long‑term durability in all fuel types
• Three 90‑degree AN‑6 fittings (2 feed, 1 return)
• Modern OEM‑style fuel float, remote mounted for ease of installation
• Designed, manufactured, anodised, and assembled in Australia

Construction & Components

• Billet aluminium fuel pump hat (V3 design)
• High‑current 6‑pin electrical bulkhead connector
• Convoluted internal fuel hose suitable for all fuel types
• Stainless steel clamps
• Connectors, hoses, and mounting hardware included
• Multiple pump cradle options available depending on configuration

Fuel Pump Compatibility

This kit is available with cradle options to suit multiple pump styles, including:

• Bosch Motorsport BR540
• TI Automotive GSS Style 39 mm
  • GSS341
  • GSS351
  • GSS342
  • GSS352
  • Other 39mm straight‑body fuel pumps (AEM / Raceworks‑style)
• TI Automotive DCSS 39/50 mm
  • F90000267
  • F90000274
  • F90000285/F90000295

Note: Fuel pumps are not included. Pump cradle selection and optional extras are chosen at purchase.
